Green
Sewn loops
QUICK SPECS:
- Stretch
- 7.9% @ 5kN · 11.2% @ 10kN
- Design
- Flat, 100% PA
- Weight
- 55 g/m (3.7 lbs / 100 ft)
- MBS
- 29.32 kN (6,591 lbf)
- Sewn Loop MBS
- 26.72 kN (6,007 lbf)
- Width
- 24.7 mm (0.97 in)
- Thickness
- 2.8 mm (0.11 in)
Batch W24SZ View batch report
Description
Introducing the all new Green Slackline Webbing! A lightweight, low-stretch, Nylon webbing that is fantastic for longer projects on nylon! The dense weave and bi-color design offered by Green gives it great handling on longer projects and superior abrasion resistance for those heavy sessions.
Green is one of the most stable webbings out there for walking. If you are searching for a line that is good for big projects with a bit of bounce, Green is the webbing for you.
Designed and Inspected in Lyons, CO. Manufactured in United States.
Pillowed Edges for Friendly Catches
Get the feeling of those pillows between your feet!
One of the most advanced features of Green is the Pillowed Edges. The internals on the edge contruction are made from 100% nylon fibers which stay loose even when the webbing is under tension. This allows the edges to be pliable and malleable while the line is tight, which gives the edges a pillow-feel, molding under your hands and feet when you grab and walk on the line. This feature makes Green a true pleasure to interact with.
Unlike some of our other pillowed edge webbings, which are primarily made from Polyester, Green is a nylon webbing. By changing the size, texture, and bundle size of the pillowing material, we were able to achieve the soft and pliable pillowed edge on Green even though it's the same material as the pillowing. This gives Green an astounding feel while walking, as the edges just form under your foot and hand, making for a very pleasureable walk.
Vibrant Colors Scheme
With only white and green as the colors, Green makes it look fancy!
Green uses just two colors for it's design: Green and White. With these two colors, we've combined them in a way to make Green look very complex and intricate. This color scheme is very pleasant to look at while cruising a big line, and also is quite visible with the sky or mountains as the backdrop.
About This Webbing
Certification, design, materials, compatibility and sewing — the fixed properties of this webbing, the same on every batch we weave.
Material
- Material
- 100% Nylon (Polyamide)
- Weave structure
- Flat
- Weave features
- Pillowed Edges
- Weave zoning
- Four-Zone Construction with Strength, Bi-Color Outer, Edge, and Pillowed zones
Walkability
- Style
- Best used for walking big projects with playfulness.
- Optimum tension
- 1.0 - 4.5 kN (225 - 1,000 lbf)
- Preferred lengths
- 60 - 400m (200 - 1,312 feet)
Highline
- Highline approved
- Yes
- Backup length
-
How long should the backup be with a Green mainline?
Mainline Backup 50 m 54 m 60 m 64.8 m 100 m 108 m 120 m 129.6 m For any other length, make the backup 8% longer than the main.
Compatible hardware
- Webbing Anchors
- Webbing Grips
Sewing
Sewn Loop
29.1 kN MBSmean 31.1 kN
3D preview Click to interact Drag to tumble · scroll to zoom · double-click to reset
Join Stitch
3D preview Click to interact Drag to tumble · scroll to zoom · double-click to reset
| Sewn LoopPattern 512 | Join StitchPattern 305 | |
|---|---|---|
| Pattern | 512 · Bartack ramp for 25 mm webbings | 305 · Double bartack ramp for 25 mm webbings |
| Pattern dimensions | 65.5 × 20 mm (L × W) (2.6 × 0.8 in) | 76 × 20 mm (L × W) (3.0 × 0.8 in) |
| Opening size | 139 mm (5.5 in) | Not applicable |
| Webbing fold | 210 mm (8.3 in) | Not applicable |
| Overlap length | Not applicable | 86 mm (3.4 in) |
| Sleeve length | 200 mm (7.9 in) | Not applicable |
| Bobbin thread | Amann Xtreme Tech with Dyneema · 220-tex · Yellow | Amann Xtreme Tech with Dyneema · 220-tex · Yellow |
| Needle thread | Amann Xtreme Tech with Dyneema · 220-tex · Red | Amann Xtreme Tech with Dyneema · 220-tex · Red |
| Stitches | 176 | 197 |
Test Data
Measured values from the current production batch (W24SZ · Dec 2024). These update with every batch we produce.
Dimensions
- Width
- 24.7 mm (0.97 in)
- Thickness
- 2.8 mm (0.11 in)
- Weight
- 55 g/m (3.7 lbs / 100 ft)
Strength
- MBS
- 29.32 kN (6,591 lbf)
- WLL
- 10 kN (2,181 lbf)
- Alpine WebLock
- 29.25 kN (6,576 lbf)
- MightyLock
- 27.46 kN (6,173 lbf)
- Sewn Loop
- 26.72 kN (6,007 lbf)
Stretch
Green's stretch curve makes it a dream to walk.
Compared to most nylon webbings, Green has a fairly low stretch, much closer to a high-stretch polyester webbing when looking at the stretch curve. This gives Green a very unique feeling while walking, making it astoundingly stable. Walking Green in the 50 - 150m range is very pleasant.
- Stretch @ 5 kN
- 7.92%
- Stretch @ 10 kN
- 11.2%
| Force | Stretch |
|---|---|
| 1 kN | 2.95% |
| 2 kN | 4.26% |
| 3 kN | 5.77% |
| 4 kN | 7.70% |
| 5 kN | 9.26% |
| 6 kN | 10.50% |
| 7 kN | 11.61% |
| 8 kN | 12.61% |
| 9 kN | 13.43% |
| 10 kN | 14.22% |
| 11 kN | 14.89% |
| 12 kN | 15.41% |
